Protected: 2 Channel Professional Amplifier TC-2200B
As a crucial component in professional sound system, itc professional amplifier plays a pivotal role in delivering high-fidelity sound and reproducing audio sources with exceptional accuracy and force, effectively filling venues with rich, clear, and dynamic sound and achieving an unparalleled listening experience.
-
Output power Stereo@8Ω: 200W×2 Stereo@4Ω: 400W×2
-
Input sensitivity 2.2dBU(1V)
-
Input impedance 10KΩ
| Model | TC-2200B |
| Output power | Stereo@8Ω: 200W×2
Stereo@4Ω: 400W×2 |
| Input sensitivity | 2.2dBu(1V) |
| Input impedance | 10KΩ |
| Frequency response (@1W Power) | 20Hz-20KHz/±1dB @8Ω |
| THD+N (@1/8 power) | ≤0.01% |
| Isolation (@1KHz) | ≥80dB |
| Damping coefficient(@1KHz) | ≥200@ 8 ohms |
| SNR (A-weighted) | ≥93dB |
| Input voltage | ~220V/50Hz |
| Overall power consumption | 150W |
| Dimension (L*W*H) | 484*206*44 |
| Weight | 3.3kg |
Technical Specification
Some words for solution selections description
-
Built-in DSP processor
+- Realize various scene presets
- Sound processing functions such as reverb, echo, howling, noise cancellation, aviation, equalization, and pitch shifting
-
Optional control methods
+- IRremote control
- Coding switch
- Button control
-
Independent adjustment of microphone and music
+- Volume adjustment
- Effect adjustment
- Treble/alto/bass adjustment
- Input gain adjustment
-
Built-in 48V phantom switch control function
+ -
Comprehensive protective measures
+- Soft start protection
- Overvoltage protection
- Undervoltage protection
- Overload protection
- Short circuit protection
- Overheat protection
